台历单/双线圈装订机 挂历单/双线圈装订机 笔记本单/双线圈装订机“封面”限位开关是用来主动约束“封面”上升高度，当“封面”用到限位

    开关闭合时，“封面”主动上升到恰当方位。

Cover limiting switch is to limit lifting height automatically. Cover will be lifted to highest position if cover limiting switch is off.

台历单/双线圈装订机 挂历单/双线圈装订机 笔记本单/双线圈装订机冲“封面”时，触摸屏上纸张厚度设定就不起作用了，是由“封面”限位开

    关来操控上升量。

The setting of paper thickness on the touch screen will not work when punching cover. It’s controlled by cover limiting switch.

台历单/双线圈装订机 挂历单/双线圈装订机 笔记本单/双线圈装订机运转留意事项 running attentions：

 运转中不要将手放在运动部件如模具等区域。

    Don’t put hands into running sections such as moulds when machine is running.

    调查皮带有无松脱现象。

    Observe if belt get loose or not.

    留意碎纸抽屉内纸屑不要过多溢出，避免纸屑堵住出口。

    Note that waste paper in the drawer can’t be too much to overflow and stem the exit.

    保证各个维护开关不受损移位。

    Make sure that all the protection switches are not damaged.

    不要长期大厚度作业，这样会形成冲针及模具过快磨损。

    Not work under big thickness situation for long time. It will wear punching needle and moulds too fast.

台历单/双线圈装订机 挂历单/双线圈装订机 笔记本单/双线圈装订机 毛病扫除 Stoppage remove

       6.1   毛病现象：台历单/双线圈装订机 挂历单/双线圈装订机 笔记本单/双线圈装订机机器不动

            发生原因：电源没有接通或许维护开关触发

            扫除办法：检查电源开关是否现已接通，维护开关有无反常， 配

                      电箱内空气开关是否断开

            Stoppage: machine not runs

            Reason: power off or protection switch is touched off.

            Remove methods: check if the power switch is on, or if protection switch is normal, or if air switch in the electric box if off.

      6.2   毛病现象：台历单/双线圈装订机 挂历单/双线圈装订机 笔记本单/双线圈装订机冲孔纸边距不稳定，不对称。

            发生原因：拍纸器及挡纸板未固定结实或与纸张空隙太大。

            扫除办法：调整紧固。

            Stoppage: paper margins are not stable or symmetrical.

            Reason: paper patter and paper board are not stable, or the distance from paper is too much.

            Remove methods: fasten above mentioned parts.

     6.3    毛病现象：台历单/双线圈装订机 挂历单/双线圈装订机 笔记本单/双线圈装订机毛边大

           发生原因：纸张太厚，冲针严峻磨损

         扫除办法：正常运转纸张厚度主张在1.2mm之内；如果是冲针磨损严峻请替换。

          Stoppage: big deckle edge

          Reason: paper is too thick or punching needle is heave wear.

          Remove methods: suggest to work less than 1.2mm. please change punching needle if is heavy wear

6.4    毛病现象：台历单/双线圈装订机 挂历单/双线圈装订机 笔记本单/双线圈装订机纸张不能顺畅进出模具

       发生原因：A.不锈钢导纸板与纸张间隔过大或压的太紧，不利于纸张顺畅收支模具。B.纸边距挡纸板与模具过紧或过松，特别是替换模具时因为装置及制作的差异有时会形成动作不灵敏。

          扫除办法：调整不锈钢纸板或纸边距挡纸板方位。

          Stoppage: it’s difficult to run in or out the mould

          Reason: A. the distance between stainless steel paper feeding board and paper is too big or pressed too strict. B. the distance between paper margin board and mould is too big or pressed too strict. Especially the differences caused by installing the mould will lead to not smooth.

          Remove methods: adjust stainless steel and margin paper board position.
