| 1 | 沙迪克i3200计算机根底操控器/Lynuc i3200 PC Base Controller |
| 2 | 双程序操控器/Dual Process Control |
| 3 | 5轴切削（X,Y,Z,X2.Z2）/Five Cutting Axes (X,Y,Z,X2,Z2) |
| 4 | 嵌入式主轴/Built-in-spindle on mains spindle |
| 5 | 主轴0.1° 分度/Spindle indexing on main: 0.1 degree |
| 6 | 嵌入式副轴/Built-in-spindle on sub spindle |
| 7 | 副轴0.1°分度/Spindle indexing on sub :0.1 degree |
| 8 | C轴操控（线性）C axis control (Contouring) |
| 9 | 夹紧设备切换/Chucking system by the toggle |
| 10 | 6外径旋转工位12x12/6OD turning station, 12x12 |
| 11 | 5内径刀具工位，ER11/ 5 ID tool station, ER11 |
| 12 | 4工位横向钻孔设备 E11/4 station Cross Drilling Unit, E11 |
| 13 | 零件顶出和承认/Part ejection & confirmation |
| 14 | 2件独自的内径刀架（D20，ER11） /ID tool holder, (D20, ER11), 2 pcs, single |
| 15 | 4工位后端刀具单元/4 station backend tool unit |
| 16 | 零件料道和存储/Part chute &stocker |
| 17 | 零件传送/part conveyor |
| 18 | 冷却设备/Coolant device |
| 19 | 12寸五颜六色液晶监视器/12" LCD color monitor |
| 20 | 2G内存/Program Memory : 2G |
| 21 | 工作灯（单）/Work light (single) |
| 22 | 刀尖和刀径补偿/Tool nose & radius compensation |
| 23 | MPG主动程序盯梢/Automatic program trace by MPG |
| 24 | 程序模仿2D,3D/Program Simulation 2D, 3D |
| 25 | 程序运转盯梢功用/Program run trace function |
| 26 | 手轮/MPG |
| 27 | 信号灯(单色)\Signal Tower (monochrome) |
| 28 | 全封闭防飞溅罩壳\Fully covered splashguard |
| 29 | 冷却箱和回流设备\Coolant tank and manihold |
| 30 | 会集光滑设备（报警）/Centralized lubrication unit (alarm) |
| 31 | 东西箱和东西\Tool box & service tools |
| 32 | 冷却液水平面测量表\Coolant level gage |
| 33 | 螺纹重复循环\Thread repetitive cycle |
| 34 | 刚性攻丝\Rigid tapping |
| 35 | 偏置量： 99个\Offset No : 99 pcs |
| 36 | 后台修改\Background editing |
| 37 | 主动断电\Automatic power off |
| 38 | 水平底脚&螺钉\Levelling pad & bolt |
| 39 | 送料器端口\Barfeeder Interfacing |
| 40 | 保质期1年\Warranty : 1 year |
| 选配/Optional Accessory |
| 1 | 工装导套架\Stationery Guide Bush Holder |
| 2 | 回转导套架\Rotary Guide Bush Holder |
| 3 | 2工位后端活动刀单元\2 station backend live tool unit |
| 4 | 3工位后端活动刀单元3 station backend live tool unit |
| 5 | 附加外径刀块 2件\Additional OD tool block, 2 pcs |
| 6 | 变压器：10KWA\Transformer : 10KVA |
| 7 | 变压器：15KV\Transformer : 15KVA |
| 8 | 堵截检测设备\Cut-off detector |
| 9 | 长零件排料设备\Long part discharging unit |
| 10 | 内径刀库设备的偏疼钻和气动主轴\Off-center drill/air spindle on ID tool unit |
| 11 | 内径刀库设备的偏疼钻和动力主轴\Off-center drill/power spindle on ID tool unit |
| 12 | 副轴的1个偏疼钻和动力主轴\1 Off-center drill/power spindle on sub spindle |
| 13 | 副轴的2个偏疼钻和动力主轴\2 Off-center drill/power spindle on sub spindle |
| 14 | 横钻带视点钻孔\Angle-head drill on cross drill |
| 15 | 副轴带视点钻孔\Angle-head drill on sub spindle |
| 16 | 后端刀具带视点钻孔\Angle-head drill on backend tool |
| 17 | 后端刀具带铣削器/Slotter on backend tool |
| 18 | 副轴的2个U形钻架/2 U-drill holder on sub spindle |
| 19 | 附加的输入输出板\Additional I/O board |
| 20 | 开裂检测软件\Cut-off detector by software |
| 21 | M代码吹气设备\M-code air blow |
| 22 | 冷却液流量检测器\Coolant flow detector |
| 23 | 气轴\Air Spindle |
| 24 | 特殊外径刀具\Special OD tool |
| 25 | 编程费用\Programming cost |
| 26 | 一个零件的刀具费\Tooling fee for one part |
| 27 | 液体冷却主轴\Liquid cooling spindle |
| 28 | 内径刀架ER11\ID tool holder ER11 |
| 29 | 内径刀绷簧夹头帽ER11\ID tool holder cap ER11 |
| 30 | 装置东西\Setting tool |
| 31 | 主动编程体系\Automatic Programing system |
